The product is simple and practical, easy to operate, compact and flexible. The new LED coaxial lighting provides you with the best par-focus, clear and clear three-dimensional image. Widely used in other surgical departments such as ENT, dentistry, orthopedics, etc.
Performance Parameters of Operation Microscopes series | |||||
Model | YSX101 | YSX102 | YSX120 | YSX130 | YSX180(12.5XEyepiece) |
Observation angle | Straight | 45°inclined | Straight | 45°inclined | 0-180°Variable angle binocular tube |
Magnificating rate of obvervation tube | 6X | 8.3X | |||
Rang of Pupillary distance | 50mm-80mm | 49mm-80mm | |||
Diopter adjustment range | ±5D | ||||
Fixe-focus large objective lens | F=200mm and F=250mm; with fine adjustment device, adjustment range ±10mm | ||||
Magnification changer | Three gear zoom: 0.6X, 1X, 1.6X | ||||
Total magnification | 16mm-81mm | 13mm-66mm | 16mm-81mm | 13mm-66mm | 15mm-80mm |
Linear field | 2.4X-12X | 3X-16X | |||
Beamsplitter | No Nil | Splitter 2:8 (optional 5:5) | |||
Camera adapter | No Nil | Can be connected to C-mount 1/3 inch CCD camera | |||
Illumination system | Coaxial LED lighting, adjustable brightness, illuminance>40,000LX, lifespan>50,000 hours | ||||
Filter | Built-in green and orange filters | ||||
Balanced arm | 2 arms, with universal adjustment | 2 arms, with universal adjustment, adjustable weight and lock | |||
Fool stand | Two-section column, five-star base | ||||
Input power | Adapter output: DC12V/3A; power: 36W | ||||
Weight per unit | 59KG (1 set and 2 boxes) | 63KG (1 set and 2 boxes) | 64KG (1 set and 2 boxes) |
