YDJ series vaginal microscope is a precision optical instrument specially developed for gynecological examination and diagnosis. Due to the magnification of the instrument, the instrument can clearly find vaginal lesions that cannot be observed with the naked eye, which greatly improves the accuracy of diagnosis
Can be customized according to customer needs
Performance Parameters of colposcope YDJ series | |||
Model | YDJ-Ⅱ | YDJ-Ⅱ-1 | YDJ-Z |
Observation angle | 45°inclined binocular tube | ||
magnification oferepice | 16X | 10X | |
Rang of Pupillary distance | 45mm-80mm | ||
Diopter adjustment range | ±5D | ||
large objective lens | F=300mm | ||
Magnification changer | 5-step Magnification:0.4X,0.66X,1X,1.5X,2.5X | Continuous zoom magnification:0.4X;-2.75X,Magnificating rate:1:7 | |
Total magnification | 2.7X-21.7X | 2.33X-16.04X | |
Linear field | 11mm-88mm | 13mm-80mm | |
Beamsplitter | Beam splitter 2:8(optional5:5) | Beam splitter5:5 | |
Camera adapter | compatible with c-mount 1/3"" CCD camera | ||
Fine focusing distance | 20mm | 60mm | 20mm |
Illumination system | 10W Coxial LED illuminator with brightness adjustment. Illumination >25,000LX. life time is over 50,000 hours | ||
Filter | Built-in green and blue filer | ||
Balanced arm | Adjustable and re-settable weight | Nil No | Adjustable and re-settable weight |
Stand | 5-star base | Horizontal 5-wheel rolling base | 5-star base |
Input power | Adapter output:DC12V/3A;Power:36W | ||
Weight per unit | 48KG 2 ICTNS/SET | 17KG 1 CTN/SET | 48KG 2 ICTNS/SET |
